Seamless Omega Steel Pipe For Boiler
- Standard
technology agreement ：XTG-JS-C-0707-2017
- 20GChemical Component
| Element | C | Mn | P | S | Si |
| Min | 0.17 | 0.35 | 0.17 | ||
| Max | 0.23 | 0.65 | 0.025 | 0.012 | 0.37 |
| Actual value | 0.18 | 0.58 | 0.016 | 0.005 | 0.33 |
- Mechanical Property
| Mechanical Property | Tensile Strength MPa | Yield Strength MPa | Elongation % |
| Min | 410 | 245 | 24 |
| Max | 550 | ||
| Actual value | 485 | 347 | 28 |
- Typical Size
| Size | Size and Tolerance（mm） | ||||||||
| a | b | c | d | e | f | H | h1 | h2 | |
| Φ53*7.5 | 10.5(-1.5,0) | 7.5±0.8 | 7.5±0.8 | 8.8(-0.4,+1.0） | 8±0.8 | 8±0.8 | 66(-1.4,0) | 58(-1.4,0) | 53(-0.7,+0.3) |
5.Typical application
It is mainly used for heat exchange tubes used in nuclear power stations and power station boilers.
