10305-2 Cold Drawn Welded Steel Tube

BSI – BS 10305-2 Specification for welded cold drawn steel tubes for automobile, mechanical and general engineering purposes – Specific requirements for cold drawn Welded Steel Tubes. cold drawn seamless tubing possesses a high strength-to-weight ratio and can be processed to provide a combination of desired characteristics: dimensional accuracy; good surface quality; excellent micro-structure uniformity; good machinability; and high tensile properties. It is also suited for such post-treatments as carburizing and heat treating.

Benefits Of 10305-2 Welded Steel Tubes

Higher Strength & Hardness Properties

Size Accuracy

Enhanced Appearance

Uniform Micro-structure

Easier To Machine

Superior Finish In Subsequent Manipulations

10305-2 Welded Steel Tubes Applications

1.Hydraulic Cylinders

2.Auto and Truck Axles

3.Suspension parts and shock absorbers

4.High Speed Shafts and rollers

5.Bearings and Spacers

6.Roll cages

7.Agricultural components and many other machined tubular parts.

Standards

BS EN 10305-2 specific requirements for cold drawn Welded Steel Tubes

10305-2 Welded Steel Tubes Chemical Component

Steel name Steel number C Si max. Mn max. P S
E155 1.0033 0,11 0,35 0,70 0,025 0,025
E195 1.0034 0,15 0,35 0,70 0,025 0,025
E235 1.0308 0,17 0,35 1,20 0,025 0,025
E275 1.0225 0,21 0,35 1,40 0,025 0,025
E355 1.0580 0,22 0,55 1,60 0,025 0,025

10305-2 Welded Steel Tubes Mechanical Property

Steel name Steel number +N
Rm R eeH A
MPa MPa %
E155 1.0033 270 to 410 155 28
E195 1.0034 300 to 440 195 28
E235 1.0308 340 to 480 235 25
E275 1.0225 410 to 550 275 21
E355 1.0580 490 to 630 355 22

10305-2 Welded Steel Tubes Delivery Condition

Normalized +N After the final cold drawing operation the tubes are normalized in a controlled atmosphere.

10305-2 Welded Steel Tubes Drawing Process

Floating/Drawing process of pulling a metal bar, rod, or wire through the whole of a die to alter its finish, shape, size, and/or mechanical properties. The tube drawing technique reduces the outer diameter, inner diameter, and wall thickness of the tube.

10305-2 Welded Steel Tubes Annealing Process

Annealing is used to soften the metal before further cold working or fabrication processes, and improves the overall metallurgical microstructure of the tube. During tube reduction or cold drawing, it can become hard and somewhat brittle. To be able to draw the tube again, stresses formed during cold working need to be removed to return the material to its normal state.

During annealing the tube is heated to a controlled temperature (up to 2100°F) and soak time. Through this process the tube remains in shape, but the grains in the structure of the tube reform into a regular unstressed pattern. The resulting annealed tube is softer and suitable for redrawing.

10305-2 Welded Steel Tubes Manufacturing process

The tubes shall be manufactured from electric welded pre-tubes by cold drawing or other suitable processes. The tubes shall not include welds used for joining lengths of flat rolled strip prior to forming the pre-tube.

10305-2 Welded Steel Tubes Packaging

Straight lengths of seamless tubing can be individually sleeved in paper or plastic and/or packaged in our unique cardboard spacers to ensure no damage occurs during transit. Coiled seamless tubes are horizontally packed using paper or cardboard separators to prevent tube-to-tube contact. All tubing is packed in either wooden crates lined with wax craft paper, tri-wall clay-coated reinforced cases, or standard cardboard boxes. Plastic end caps that prevent foreign material from getting inside the tubes are also available upon request.

Other Services

1 Cutting: Small pieces

2 End: Plaint or Beveled or threaded

3 CNC Machine: Produce as your drawing

4 Package: Bare/Nylon/Canvas/Wooden

5 Payment:T/T, L/C, O/A(request credit)

6 Transport:FOB/CFR/CIF/DDU/DDP (train/ship/Air)

Contact Fushun 10305-2 Welded Steel Tubes Today

Contact us for more information regarding precision steel tubing specifications and product options, or request a quote for further pricing details today.

Experienced 15+ Years

Our ability to purchase materials directly from leading mills at the best possible price will give you the competitive edge. This coupled with a skilled workforce dedicated to embracing the demands of the markets.

We Can Supply Follows Products with High Quality:

  1. Cold Rolled Steel Tube
  2. Cold Drawn Steel Tube
  3. Hollow Bar
  4. Honed Tube
  5. Plated Tube
  6. Plated Bar
  7. Boiler Tube

All Products According Quality Standard Strictly:

  1. ASTM: ASTM A519, ASTM A513.
  2. JIS:JIS G3441, JIS G3445, JIS G3466, JIS G3459.
  3. DIN: DIN1626, DIN1629, DIN2391, DIN2393, DIN2448, DIN2458.
  4. EN: EN10305.
  5. BS: BS6323.

Wide Range of Pipes to Fit Your Industry:

  1. OD from 5mm to 820mm.
  2. Wall Thickness from 0.1 to 100mm.
  3. Length up to 50mtr per pc.
